Part # 10040365 (Legacy Part #K2372PS)

Part #10040824 (Legacy Part # SS211PA6)

Standard Tube Mount Quarter Fender

Specifications:

Finish: Bright 430 18 Gauge Stainless Steel
Mounting Tube & Clamp Finish: Bright 430 18 Gauge Stainless Steel
Mounting Option: None
Top Flap Hardware: Stainless Steel
Packaging: Boxed Individual
Contents: Includes Tube Mounting Clamp, Top Flap and Top Flap Mounting Hardware
Top Flap Details: Black Poly, Plain No Logo
Handedness: Left

Fenders and Brackets Poly Fenders & Brackets

Part #10040817 (Legacy Part # PS221PA6)

Low Tube Mount Quarter Fender

Specifications:

Handedness: Left
Packaging: Boxed Individual
Contents: Includes Tube, Mounting Clamp, Top Flap, and Top Flap Mounting Hardware
Fender Finish: Black High Density UV Resistant Poly
Mounting Tube and Clamp Finish: Galvanized 18 Gauge Carbon Steel
Top Flap Hardware: Zinc Plated Steel
Top Flap Details: Black Poly, Plain, No Logo

Fenders and Brackets Metal Fenders & Brackets

Part # 10040392 (Legacy Part #L200TS)

Triangle Fender Brackets

Specifications:

Application: Single Axle Fender Mounting Kit
Frame Mount: Single-Bolt Post Frame Mount
Bracket Type: Four (4) B610TS Stainless Steel Paddle Brackets
Bracket Quantity: 4
Finish: Bright 304 14 Gauge Stainless Steel
Hardware / Material, Quantity and Part Number: Four (4) X2900; Four (4) TS100H-1 (Contains Six (6) Cap Screws and Lock Washers and Three (3) Washer Plates; Four (4) 400118-01

Single Axle Brackets Fenders and Brackets

Part # 10040346 (Legacy Part #H2274UG)

Tube-Style Fender Brackets

Specifications:

Applications: 2-Rib, 4-Rib, Smooth, Corrugated
Fender Type: Galvanized Steel
Front and Rear Bracket Type / Quantity and Part Number: Single-Bolt Frame Mount, Undrilled Galvanized Tube / Two (2) T274UG
Tube: Undrilled
Hardware / Material, Quantity and Part Number: Galvanized U-Bolts / Two (2) CG100H-1 Each Contains Four (4) U-Bolts, Lock Nuts and Washer Plates
Tube Mount / Length, Mounting Hole, Finish, Material: 26.500″, …
